Cylindrical Lithium Battery

Lithium Ion Battery 3C ICR21700 5000mAh Customized service, 7.4V 11.1V 22.2V 48V 3.7v can be packed as per custome requirements.

Cylindrical Lithium Battery

Lithium Ion Battery 3C ICR21700 5000mAh

  1. First-class brands cell, and choose the best among the best.
  2. Internal synchronization for reliability testing.
  3. The high-precision automatic matching machine improves the consistency of the battery pack and the cycle life of the whole pack.
  4. Fully automatic laser welding reduces the internal resistance of the finished product and is not easy to desolder.
  5. The battery is 100% aged before leaving the factory.
SKU: 3.7V LCR21700 5000mAh Category: Tags: , , , , ,
Category
Cylindrical Lithium Battery
Price: project quote
Customization available

Lithium Ion Battery 3C ICR21700 5000mAh

Battery model LCR21700
Nominal voltage 3.7V
Nominal capacity 5000mAh
Standard charging current 2500mA (0.5C)
End current 50mA (0.01C)
Max. charging current 5000mA (1C)
Standard discharging current 2500mA (0.5C)
Maximum Continuous Discharging Current 15000mAh (3C)
Discharging cut-off voltage 2.75V
Shipment Voltage 3.7V~4.0V
Charging temperature range 0~45℃
Discharging temperature range -20~60℃

Lithium Ion Battery 3C ICR21700 5000mAh

Project request

Request product information

Tell us about your project and customer profile. The form structure follows the supplied inquiry workflow, including company/individual selection and conditional business questions.

Only name, country/region and email are required. All other fields are optional.

Tailored engineering

Product customization

Define the electrical, mechanical, protection, installation and production requirements for engineering review. Final configuration, safety limits, certification and tooling remain subject to MOTOMA approval.

ProductLithium Ion Battery 3C ICR21700 5000mAh
ElectricalVoltage / power / capacity review
IntegrationConnection / communication / protection
ApprovalSample + compliance review

Only name, country/region and email are required. All other fields are optional.

1. Contact and project
2. Electrical requirements
3. Mechanical and connection
4. Protection and compliance
Attach drawings or specifications where available.

Custom product projects require technical feasibility review, safety validation and the appropriate compliance plan before mass production.
